| Inner Thread |
Outside Thread |
Lenght |
Drilling Diameter
Consultation |
Minimum
Drilling
Deepth |
The Meter
System |
The Metric
System |
External
Diameter |
PH |
(L) |
Plastic |
Aluminum |
Castlron |
| M2.5 |
#2 |
4.5 |
0.5 |
6 |
4.0-4.1 |
4.1-4.2 |
4.2-4.3 |
8 |
| M3 |
#4 |
5 |
0.5 |
6 |
4.5-4.6 |
4.6-4.7 |
4.7-4.8 |
8 |
| M3.5 |
#6 |
6 |
0.75 |
8 |
5.3-5.4 |
5.5-5.6 |
5.6-5.7 |
10 |
| M4 |
#8 |
6.5 |
0.75 |
8 |
5.8-5.9 |
6.0-6.1 |
6.1-6.2 |
10 |
| M5 |
#10 |
8 |
1 |
10 |
7.1-7.2 |
7.3-7.5 |
7.5-7.6 |
13 |
| M6(A) |
#12 |
9 |
1 |
12 |
8.1-8.2 |
8.3-8.5 |
8.5-8.6 |
15 |
| M6 |
#1/4" |
10 |
1.5 |
14 |
9.0-9.2 |
9.2-9.3 |
9.3-9.4 |
17 |
| M8 |
#5/16" |
12 |
1.5 |
15 |
10.6-10.8 |
11.0-11.2 |
11.2-11.4 |
18 |
| M10 |
#3/8" |
14 |
1.5 |
18 |
12.6-12.8 |
13.0-13.3 |
13.2-13.4 |
22 |
| M12 |
#7/16" |
16 |
1.5 |
22 |
14.6-14.8 |
15.0-15.3 |
15.2-15.4 |
26 |
| M14 |
#1/2" |
18 |
1.5 |
24 |
16.6-16.8 |
17.0-17.3 |
17.2-17.5 |
28 |
| M16 |
#5/8" |
20 |
1.5 |
22 |
18.6-18.8 |
19.0-19.3 |
19.2-19.5 |
27 |
| M18 |
|
22 |
1.5 |
24 |
20.6-20.8 |
21.0-21.3 |
21.2-21.5 |
29 |
| M20 |
|
26 |
1.5 |
27 |
24.6-24.8 |
25.0-25.3 |
25.2-25.5 |
32 |
| M22 |
#3/4" |
26 |
1.5 |
30 |
24.6-24.8 |
25.0-25.3 |
25.2-25.5 |
36 |
| M24 |
#7/8" |
30 |
1.5 |
30 |
28.6-28.8 |
29.0-29.3 |
29.2-29.5 |
36 |
| M27 |
|
34 |
1.5 |
30 |
32.6-32.8 |
33.0-33.3 |
33.2-33.5 |
36 |
| M30 |
|
36 |
1.5 |
40 |
34.6-34.8 |
35.0-35.3 |
35.2-35.5 |
46 |
